SRT BH9022 1/8-1/10 HV METAL CASE 22KG 0.06S. BRUSHLESS SERVO
Application:
1/10 on road, 1/8 off road & Helicopter
Specifications:
CNC Alloy case
Bearing: Dual
Motor Type: Brushless
Gear Material: Titanium & Alu
Voltage: dc 6.0-8.4v
Speed (6.0v): 0.085 sec/60 deg.
Spd. (7.4v): 0.065 sec/60 deg.
Spd. (8.4v): 0.060 sec/60 deg.
Torque (6.0v): 18.0kg.cm
Torque (7.4v): 20.0kg.cm
Torque (8.4v): 22.0kg.cm
Dimensions: 40x20x38.0 mm
Weight: 70g
Connector wire length: jr 250 mm
€100.00
VAT included
Secured Payment
Super Fast Delivery
Flexible Return Policy
Overview:
The latest generation of SRT servos provides you with the performance you need for any scale vehicle Air PlaneBoatRobot application. are standard size servos for High-Voltage applications up to 8.4V, feature all metal case construction for the ultimate performance.
Features:
- Ideal for 1/10 on road and 1/8 off road scale applications
- Superior Holding Speed
- incredible efficiency and low power consumption
- Standard dimension make it perfect for vehicles that can benefit from a high quality servo
- CNC Machined aluminum case for exceptional cooling
- NMB dual main bearings
- 25T output shaft
- HD 4096 Resolution
- 2 μsec Dead Band
SRT-BH9022
